The Family All-Rounder

Why Choose SF20H?

The SF20H is the perfect all-rounder for families and daily riders, offering a seamless blend of convenience and versatility. Its foldable design makes storage and transport effortless, while the sturdy rear frame allows you to carry children, pets, or groceries with ease. Although compact, it packs a punch—one bike that brings all the convenience a family needs.

View Tech Spec

Rider Review

VTUVIA SF20H 20 inch fat tire folding electric bike for all terrains

1200 Peak Power Boost

Small When You Need, Strong When You Ride. Effortless Riding Even with Passengers or Cargo.

-Torque 85Nm
-Shimano 7-Speed
-Class 2 Speed w/ Thumb Throttle
-5-Level Pedal Assist

VTUVIA SF20H 20 inch fat tire folding electric bike with passenger seat

Carry Life, Ride Happy

The SF20H is a foldable cargo e-bike with a welded rear frame, capable of carrying up to 330 lbs. It's perfect for transporting children and pets, offering both convenience and safety for your daily rides.

-Compact & Foldable Design
-Max Load: 330 Lbs
-Up To 70 Miles Range

VTUVIA SF20H 20 inch fat tire folding electric bike for all terrains

Safety Meets Comfort

Ride with Peace of Mind, Where Safety and Comfort Take You Further Without Compromise.

-UL2849 Safety Certified
-Dual Hydraulic Brakes
-Front Suspension
-20x4" Anti-Slip Reflective Tires

More Details

Foldable Size: 28.7x33.8x12.2"

Compact design, allowing for easy storage and transport, perfect for those with limited space or for taking on the go.

Welded Rear Rack

The rear rack is designed for both carrying cargo and passengers. You can easily mount a child’s seat or a delivery box, with a maximum weight capacity of 330 lbs.

Dual Hydraulic Brake

Delivers strong and responsive braking power, ensuring safety and control in all weather conditions.

Suspension Front Fork| VTUVIA Electric Bikes

Hydraulic Front Fork

Provides superior shock absorption, ensuring a smooth and comfortable ride on rough terrain, whether you're commuting or exploring off-road.

UL2271 Safety Certified

Features a UL-certified battery, which greatly reduces the risk of malfunction or safety issues. With proper use, you can ride with complete peace of mind.

Rear Foot Peg

The rear foot peg provides added comfort for passengers, making the SF20H a great choice for carrying a second rider.

LCD Screen

Displays essential ride information like speed, battery life, and distance, offering clear visibility even in bright sunlight or low light conditions.

Shimano 7-Speed Drivetrain

Offers smooth, reliable gear shifting for tackling a variety of terrains and inclines, ensuring a comfortable and efficient ride.

LED Headlight

Features a powerful LED headlight to enhance visibility and safety during night rides, ensuring you can see and be seen.

Fat Tire Folding eBike | VTUVIA SF20H Fat Tire

20"x4" Fat Tires

These wide, durable tires provide excellent stability and traction on various surfaces, such as sand, snow, and rough trails.

Specs

General Info
Model
VTUVIA SF20H
Ideal use
City Commuting/Cargo Transpot
Range
Máximo 70 millas (asistencia de pedaleo)
Net weight
60 Lbs
Total capacity
330 libras
Rider height
5'3"-6'2"
Safety certifications
UL2271(Battery) UL2849(E-bike System)
Frameset
Frame
Aleación de aluminio 6061
Frame style
Paso a paso
Foldable
Fork
Front
Suspension
Horquilla de suspensión delantera EXSHO
Ebike System & Drivetrain
Motor
750 W
Speed
Clase 2
Sensor
Sensor de cadencia
Torque
85 Nm
Battery
Batería de iones de litio LG UL2271 de 48 V y 14 Ah (672 Wh)
Controller
KZQW26 48V 25A Motor de onda sinusoidal inteligente sin escobillas
Pedal assist
3 modos x 5 niveles
Throttle
Thumb Throttle
Display
3,5" a todo color
Charger
Funciona con tomas de corriente CA de 100 V a 240 V.
Charging time
Aproximadamente 7 horas
Shift lever
SHIMANO 7 velocidades
Rear derailleur
Shimano TY300D 7 Speed
Cassette
Shimano TZ5007 7 Speed 14-28T
Pedals
Pedales plegables
Wheelset & Brakes & Cockpit
Tire
20"*4.0"
Brake
Freno de disco hidráulico doble LOGAN
Brake rotors
Acero inoxidable martensítico de 180 mm (2CR13)
Stem
Aluminum Alloy Adjustable
Seatpost
Aluminum Alloy
Included Accessories
Lights
Luz de freno y faro LED
Fenders
F&R: Guardabarros estándar de plástico
Rear rack
Incluido
Kickstand
Included
Bell horn
Not Included

Geometry

Size guide
Total length
65"
Wheelbase
45"
Maximum seat height
34"
Chain stay length
19"
Standover height
16"
Top tube length
22,5"
Head tube length
4"
Handlebar length
24"
Minimum seat to floor
29"
Rider height
5'3"-6'2"

*These factors, based on laboratory tests, show that the range of an e-bike is influenced by the rider's weight, pedal assist level, throttle use, terrain, speed, weather, and towing weight. These elements affect battery consumption and, ultimately, the e-bike's range.

*Please note that, based on component availability and other factors, specifications are subject to change without notice.

*The VTUVIA SF20H comes out of the box as a Class II e-bike, equipped with pedal assist and throttle. It is UL2849 certified for safety, and due to UL certification requirements, the default maximum speed is set to 20 MPH, which can be adjusted according to user preferences. The bike is built to the IP67-rated standard, making it suitable for riding through creeks, mud, and snow. However, please avoid prolonged or intentional immersion in water. Additionally, the bike is not designed to withstand high-pressure sprays, so refrain from using pressure washers or sprayers for cleaning.

FAQs

What's the ranges of SF20H?

Pedal assist: Max 70 miles

Throttle Only: Max 40 Miles

*Note: Throttle Max Range tests are calculated using PAS 1 with a rider weight of 170 lbs on flat terrain. Throttle speed and range may vary if ridden in different conditions.

Do I need a license to ride Ebikes?

No, you don’t need a license to ride Ebikes. But please note that this is an adult ebike and you need to be over 16 years old to ride it.

How much does the SF20H weight?

Net Weight: 60Lbs

Does the SF20H have UL 2849 certification?

Yes, it has safety certified. You can search for this certification on the SGS official website.

Does SF20H arrive fully assembled?

Yes, all our electric bikes are sold 85% assembled and ready to ride.
