VTUVIA Official Guide|Hollywood RV Rider eBike Rack Installation & Usage (Checklist & FAQ Included)

A hands-on guide from a VTUVIA owner's perspective: learn how to complete the Hollywood Racks RV Rider eBike rack installation, loading, and safety inspection in 30–45 minutes. Includes real photos, display images, and a tools checklist, compatible with multiple VTUVIA models (fat tire / step-over / step-thru / folding).

View Hollywood RV Rider Rack Jump to Table of Contents

VTUVIA with Hollywood Racks RV Rider rack mounted
Real owner shot: RV Rider platform rack supports fat tires and heavy motors securely.
Table of Contents
  1. Preparation & Unboxing Checklist
  2. Step-by-Step Installation
  3. Loading & Securing Tips (Step-Thru & Folding)
  4. Pre-ride Safety Checklist
  5. VTUVIA Model Compatibility & Recommendations
  6. Maintenance & Long-term Usage Tips
  7. Frequently Asked Questions (FAQ)

1. Preparation & Unboxing Checklist

Tools Required

  • Socket wrenches (3/4", 1/2") / Open-end wrench
  • Hex key set (4–8 mm)
  • Torque wrench (recommended)
  • Scissors / diagonal pliers (for zip ties)
  • Rubber gloves, soft cloth / foam protection pad

Unboxing Checklist

  • Platform trays ×2, wheel trays ×4, clamps/arms, vertical/horizontal beams
  • Main connectors, pins & safety locks, straps & locks
  • Installation bolts/nuts/washers, manual/warranty card
VTUVIA Reminder: Please confirm your vehicle's hitch rating and load capacity meet the total weight of the rack plus eBikes. For two eBikes, calculate: rack weight + two bikes (batteries removed recommended).

2. Step-by-Step Installation

Step 1|Attach to Hitch

  1. Insert the RV Rider hitch mount into the 2” hitch receiver, align pin holes, insert the anti-theft pin, and lock it.
  2. Tighten anti-sway mechanisms (if present) until the rack is stable and no side-to-side movement occurs.

Step 2|Install Vertical/Horizontal Beams & Platform Trays

  1. Secure the vertical supports and tighten to recommended torque with a torque wrench.
  2. Attach two platform trays to the main beam, leaving space for the wheel trays to load bikes.
  3. Adjust wheel tray positions and strap lengths based on wheel size and tire width (e.g., VTUVIA fat tires).

Step 3|Install Clamps/Arms

  1. Mount the clamping arms onto the vertical beams, adjust height to press on the top tube or tires per official guidelines.
  2. Ensure rubber/soft pads contact surfaces to avoid scratching the frame or wires.

Step 4|Function Test & Fold Angle

  1. Test the tilt/fold mechanism for smooth operation (for trunk access).
  2. Fold the platform when not in use and lock pins securely.
RV Rider installation key steps demonstration
After platform and vertical beams are installed, check all pins and locks are fully engaged.

Purchase RV Rider Rack (VTUVIA Official)

3. Loading & Securing Tips (Step-Thru & Folding)

Preparation Before Loading

  • Remove batteries, lights, cyclometers, and bags (reduces weight & prevents theft)
  • Rotate pedals out of the way; lower seatpost if needed
  • Have ramp or foldable ramp ready if lifting is difficult

Standard Loading Steps (Platform Rack)

  1. Push front wheel onto the outer tray, then lift/push the rear wheel; ensure bike rests securely in wheel trays.
  2. Tighten front & rear wheel straps, make sure tires sit fully in trays.
  3. Adjust clamps/arms and lock (prefer stable points on top tube or tires).
  4. Gently shake to check stability; add secondary straps if needed.

Step-Thru Bike Securing

  • Use tire clamp or manufacturer-provided beam adapter for top tube support.
  • Avoid clamping near control wires or display units.

Folding Bikes (e.g., SF20 Series)

  • Can be placed inside SUV/MPV or mounted unfolded on the platform.
  • If folded on the rack, ensure folding lock is fully closed and secure with straps.
Highway/Long Trip Tip: Check straps and locks again due to higher wind and bumps; inspect every 100–150 km or at each long stop.

4. Pre-Ride Safety Checklist Printable

  • Hitch and main connectors locked, anti-sway mechanisms tightened
  • Platform pins & safety locks secured
  • Front & rear wheel straps tightened, clamps/arms locked
  • Batteries removed and stored inside to avoid heat exposure
  • License plate and tail lights unobstructed (add extensions if needed)
  • Secondary anti-theft: lock or cable through frame and platform
  • Drive 1–2 km, stop, and recheck all attachments

5. VTUVIA Model Compatibility & Recommendations

RV Rider is a heavy-duty platform rack, better suited for fat tires, long wheelbases, and heavier motors. Example VTUVIA recommendations:

Model Type Compatibility Notes Recommended Setup
SN100 / Gemini Fat tire MTB / Commuter Wide tires, heavy weight Use tire clamps; remove batteries
Zeal LT7 / XT8 Step-over commuter / multi-use Top tube stable Use top tube or tire clamp
SF20 Series Folding Folding lock Can be placed inside vehicle; rack mounting unfolded more stable

Carrying two eBikes? Follow the maximum load strictly; place the heavier bike closer to the vehicle.

Check stock & specs

6. Maintenance & Long-Term Tips

  • Monthly: check torque, pin wear, strap elasticity & cracks
  • After rain/snow/sea exposure: clean & dry metal parts, apply rust prevention if needed
  • Use bike cover carefully at high speed (may increase wind drag); prefer low-resistance cover or partial coverage
  • Off-season: remove rack, store upright in dry place, avoid prolonged sun or rain exposure

7. Frequently Asked Questions (FAQ)

Q1: Can a regular bike rack carry an eBike?

Depends on load rating and mounting method. eBikes are heavier; platform racks like RV Rider are recommended. Always follow maximum load & manufacturer instructions.

Q2: Do I have to remove the battery?

Strongly recommended. Reduces 2–4 kg per bike, protects battery from heat & vibration, and lowers theft risk.

Q3: Any extra precautions for highway/long trips?

Wind and vibration are stronger. Use secondary straps and periodically recheck connections & strap tightness.

Q4: How to secure Step-Thru bikes?

Prefer tire clamps; if clamping the top tube, use beam adapter and avoid display wires.

Q5: Can I use with RV/Travel Trailer?

Check rack support for RV/Trailer scenarios, follow manufacturer instructions for placement & speed limits.

Downloads & Media

For brand media or collaboration, contact VTUVIA marketing team.

© VTUVIA eBike. Some images are illustrative; actual product may vary. Follow instructions and local road regulations strictly.
